GIANNINA SB: pellet boiler
The new pellet boiler GIANNINA SB series is the result of our research in the field of solid fuel boilers. The use of a fuel economical and environmentally friendly , along with the automatic control of all aspects of our new boiler guarantee maximum savings, comfort, respect for the environment .
Thanks to a combustion efficiency of over 90 % is guaranteed a savings of 40% to 60 % on traditional fuels , liquid or gaseous . Fully automatic operation of the boiler allows you to maintain a level of comfort comparable to that obtained with traditional boilers , with range up to a week or more. Of course the quality of the fuel and the capacity of the silos used determine with greater precision these times .
The boilers GIANNINA SB are composed of a boiler body in steel quality and thick , an electronic control unit , an auger for alimentazionea fall of the fuel , of an electrical resistance for the automatic switching and fan suction .
Possibility of placing the container pellet to the right or left of the boiler , thanks to the use of a flexible connection pipe . Enjoy easy access to every part of the boiler, to the ordinary and extraordinary maintenance .
The pellet loader is constituted by a tube containing a special steel auger driven by a gearmotor extremely robust and reliable . The funnel entrance pellet is connected to the auger by means of a hose.
FEATURES
brochure-2017-giannina.pdf
Thanks to a combustion efficiency of over 90 % is guaranteed a savings of 40% to 60 % on traditional fuels , liquid or gaseous . Fully automatic operation of the boiler allows you to maintain a level of comfort comparable to that obtained with traditional boilers , with range up to a week or more. Of course the quality of the fuel and the capacity of the silos used determine with greater precision these times .
The boilers GIANNINA SB are composed of a boiler body in steel quality and thick , an electronic control unit , an auger for alimentazionea fall of the fuel , of an electrical resistance for the automatic switching and fan suction .
Possibility of placing the container pellet to the right or left of the boiler , thanks to the use of a flexible connection pipe . Enjoy easy access to every part of the boiler, to the ordinary and extraordinary maintenance .
The pellet loader is constituted by a tube containing a special steel auger driven by a gearmotor extremely robust and reliable . The funnel entrance pellet is connected to the auger by means of a hose.
FEATURES
- Efficiency at 90% with fuel pellets
- Reduced emissions
- Steel body with combustion chamber
- Dry chamber (the flame will never be in contact with the wetted parts of the boiler , thus avoiding the danger of condensation )
- Combustion chamber deep and broad partially coated refractory to ensure :
- Complete combustion of the air / pellet
- Cleaning of the walls are wet
- High energy efficiency
- Cleaning of the walls are wet
- High energy efficiency
- Insulation of mineral wool coat tear of 80 mm thick
- Automatic power through electrical resistance
- Modulation power on four levels
- Optimization of combustion through modulation of temperature modulation of the boiler flue gas temperature
- Suction fan located in the fume chamber for combustion optimization
- Control panel with display: on, off release , ACS management
- Signaling proper operation of the probes
- Protection momentary voltage
- Overtemperature protection of the boiler water
- Display of the alarms on the display
- Operation pellet , peanut , olive pomace oil and biofuel granular
- Large pellet container , positioned at the 3 sides boiler
